5423-518 Pump 5433-138 Hydraulic Tsav PMB6.0sp Reducer Rau 8-12 Lub Cev Tov Khoom Truck
Wuhan Xinlaifu Hydraulic Equipment Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov neeg muag khoom ntawm 5423-518 twj 5433-138 hydraulic lub cev muaj zog pmb6.0sp reducer rau 8-12 lub voos xwmfab tov khoom tsheb hauv Suav teb. Nrog kev paub ntau, peb sov siab txais tos koj los yuav cov khoom lag luam zoo ntawm tus nqi sib tw los ntawm peb lub hoobkas. Tsis tas li, OEM & ODM kev pabcuam muaj.
Technical specifications
| Yam khoom | Specification |
|---|---|
| Tshooj Naj Npawb | 5423-518, 5433-138, PMB6.0 ib |
| Yam khoom | Hydraulic Pump-Motor-Reducer Assembly |
| Siv tshuab | 8-12 Cube Concrete Tov Khoom Truck / Transit Tov Khoom |
| Hom Lub Npe | Qhob Transit Tov Khoom Truck 8-12 Cubic |
| Daim ntawv thov | Hydraulic tsav tsev rau 8-12 cubic qhob tov khoom tsheb tig nruas, muab lub zog rau kev sib tov nruas |
| Gear Structure | Integrated hydraulic twj tso kua mis, lub cev muaj zog thiab planetary reducer sib dhos, sib tw OEM nrog cov qauv rau kev tsav tsheb ruaj khov |
| Khoom siv | Pump & Tsav Housing: High-strength cam khwb cia hlau; Reducer Iav: Hnav-resistant Alloy Steel |
| Kev khiav tawm | Matches thawj OEM tshem tawm specification rau 8-12 cubic mixer tsheb |
| Ua Haujlwm Siab | Matches OEM tus qauv siab ntsuas rau qhob tov khoom tsheb hydraulic system |
| Installation Form | Flange mount, ncaj bolt-on installation txuam OEM mounting qhov ntev |
| Kev Ua Haujlwm | Rau kev tsim kho tshuab hydraulic roj xov xwm, hnyav-lub luag haujlwm sab nraum zoov-qhov chaw ua haujlwm ib puag ncig, sib xws nrog cov txheej txheem hydraulic kua |
| Hom sealing | Standard high-pressure roj foob, xaiv tau upgraded sealing cov khoom siv rau kev ua hauj lwm hnyav |
| Qhov hnyav | Matches OEM hnyav specification rau ncaj qha poob-hauv hloov |
| Lus ceeb toom | Txhim khu kev qha 1: 1 hloov pauv hloov tau, kev ua haujlwm zoo ib yam ntawm hydraulic, txo cov khoom siv downtime rau 8-12 cubic qhob tov khoom tsheb kho & kho nkoj |
Product Overview
Qhov no ua tiav hydraulic tsav los ua ke muaj5423-518 hydraulic twj tso kua mis, 5433-138 hydraulic lub cev muaj zogthiabPMB6.0sp planetary reducer, engineered raws li ib tug ncaj-haum hloov chav tsev rau 8-12 cubic transit qhob tov khoom tsheb. Tsim los xa cov khoom siv hluav taws xob ruaj khov rau kev sib tov nruas, cov txheej txheem no ua haujlwm raws li cov tub ntxhais hydraulic fais fab ntawm lub tshuab tov khoom nruas.
Tsim kom haum OEM qhov ntev thiab cov qauv kev ua tau zoo, lub rooj sib dhos txhawb nqa kev txhim kho tsis muaj kev hloov kho ntxiv. Heavy-lub luag hauj lwm cam khwb cia hlau thiab hnav-resistant alloy Cheebtsam ua kom lub neej ntev kev pab cuam nyob rau hauv hnyav siv-site ua hauj lwm tej yam kev mob. Standard high-pressure sealing adapts rau ib txwm hydraulic kua media rau sab nraum zoov hnyav-load ua haujlwm.
Qhov zoo tshaj plaws rau kev kho cov cuab yeej siv, kev tu lub nkoj thiab kev hloov pauv tom qab kev lag luam. 1: 1 kev sib hloov ua tau zoo txo qis lub sijhawm ntawm lub tshuab rau 8-12m³ pob zeb sib tov tsheb. Tag nrho cov lej tseem ceeb5423-518, 5433-138, PMB6.0 ibyog tag nrho matched rau ceev ib feem-ntaus-raws li kev tshawb fawb los ntawm thoob ntiaj teb machinery buyers, tu kws kho mob thiab khoom wholesalers.
Nta thiab Qhov Zoo
- Ua kom tiav kev sib koom ua ke nrog cov lej tseem ceeb5433-138, 5423-518, PMB6.0 ib, yooj yim txheeb xyuas thiab nrhiav los ntawm cov kws tshaj lij los ntawm kev tshawb nrhiav ib feem.
- Direct OEM-interchangeable unit rau 8-12 cubic transit tov khoom tsheb, poob-nyob rau hauv haum yam tsis muaj kev hloov kho ntxiv thaum lub sij hawm installation.
- Cov vaj tse muaj zog cam khwb cia hlau thiab hnav-tiv taus alloy cov khoom, kev ua haujlwm ruaj khov nyob rau hauv hnyav-load, hnyav siv-qhov chaw ua haujlwm.
- Zoo-muab hydraulic tso zis los tsav tsheb sib tov nruas kev sib hloov, muab lub zog zoo ib yam rau kev sib xyaw ua ke thiab kev thauj mus los.
- High-pressure sealing kev tsim kho, zoo sib xws nrog cov txheej txheem hydraulic kua, yoog mus rau lub sijhawm ntev kev ua haujlwm sab nraum zoov.
- Txhim khu kev txhim kho tom qab kev lag luam hloov kev daws teeb meem rau kev sib tov tsheb kho tsheb thiab kev tu lub nkoj, txo cov khoom siv poob qis.
- Puv-set pre-matched twj-motor-reducer ua ke, txuag lub sij hawm muab khoom rau cov neeg yuav khoom thoob ntiaj teb thiab pab pawg tu.
- Kev tsim khoom nruj me ntsis kom haum rau qhov loj me me thiab cov qauv kev ua haujlwm, lav qhov kev sib raug zoo rau 8-12m³ qhob tov khoom tsheb thauj khoom.
Tej kev siv
- Ua tiav hydraulic tsav hloov rau8-12 cubic qhob tsheb thauj mus los tov khoom
- Drum rotation power system kho rau ntawm txoj kev pob zeb sib tov thauj tsheb
- Tom qab kev muag khoom spare-parts muab rau mixer tsheb fleet tu tej yaam num
- Hydraulic system overhaul rau siv & ob txhais tes qhob tov khoom tsheb
- Cov cuab yeej siv kho dua tshiab rau kev tsim kho tshuab cov tsheb xauj tsev
- Kev kho nyob rau ntawm qhov chaw ntawm cov khoom sib tov tsheb hydraulic zog pawg
- Cheebtsam hloov rau cov pob zeb batching cog txhawb nqa cov khoom sib xyaw
- Lag luam wholesale spare-part matching thoob ntiaj teb machinery kho rhiav
FAQ
Q1: Dab tsi cov cav tov tau tshaj 5433-138 hydraulic lub cev muaj zog, 5423-518 twj tso kua mis thiab PMB6.0sp reducer sib dhos?
A:Qhov no ua tiav hydraulic tsav teeb yogtshwj xeeb tsim rau 8-12 cubic meter qhob tov khoom tsheb thauj khoom. Kev sib xyaw ua ke ntawm 5423-518 hydraulic twj tso kua mis, 5433-138 hydraulic lub cev muaj zog thiab PMB6.0sp planetary reducer zoo kawg nkaus phim cov khoom siv hluav taws xob qub ntawm 8-12 lub voos xwmfab kev sib txuas, kom ntseeg tau meej kev sib raug zoo thiab kev sib hloov ntawm lub nruas.
Q2: Puas yog 5433-138 / 5423-518 / PMB6.0sp los ua ke ib qho kev hloov OEM ncaj qha?
A:Yog lawm. Lub 5433-138 lub cev muaj zog, 5423-518 twj tso kua mis thiab PMB6.0sp reducer yog tsim nyob rau hauv nruj raws li OEM thawj qhov ntev, mounting qauv thiab ua hauj lwm tsis. Nws txhawbntsaws-thiab- ua si hloovyam tsis muaj kev txiav, drilling lossis hloov kho ntxiv, ua kom lub sijhawm ua haujlwm ntawm lub tsheb thauj khoom luv luv.
Q3: Puas yog qhov no 5423-518 twj tso kua mis & 5433-138 lub cev muaj zog teeb ua haujlwm rau cov tsheb sib tov sib xyaw tshaj 12 cubic meters?
A:Tsis pom zoo. Lub 5433-138 hydraulic lub cev muaj zog thiab 5423-518 twj tso kua mis yog calibrated rau lub hydraulic load thiab lub zog thov ntawm8-12 lub voos xwmfab mixer tsheb. Kev siv nws ntawm qhov loj dua - cov khoom sib xyaw muaj peev xwm yuav ua rau lub zog tsis txaus, kev ua haujlwm ntau dhau thiab ua kom nrawm nrawm ntawm PMB6.0sp reducer, cuam tshuam rau lub neej kev pabcuam thiab kev ua haujlwm ruaj khov.
Q4: Dab tsi yog qhov laj thawj tseem ceeb ntawm cov roj to rau 5433-138 hydraulic lub cev thiab 5423-518 twj tso kua mis?
A:Feem ntau yog vim li cas muaj xws li kev laus siab - cov ntsaws ruaj ruaj, cov roj hydraulic tsis raug, qhov system overpressure thiab thaiv cov kab ntws. Qhov sib tw 5433-138 lub cev muaj zog, 5423-518 lub twj tso kua mis thiab PMB6.0sp reducer txais yuav hloov kho cov qauv sib khi. Kev hloov pauv ntawm cov qauv hydraulic roj thiab kev tshuaj xyuas lub sijhawm niaj hnub tuaj yeem ua kom tsis txhob muaj qhov ua tsis tiav.
Q5: Vim li cas lub tshuab ntaus nruas khiav tsis muaj zog tom qab txhim kho 5433-138 lub cev muaj zog thiab 5423-518 twj?
A:Kev sib hloov ntawm lub nruas tsis muaj zog feem ntau yog tshwm sim los ntawm qhov tsis txaus siab, sab hauv to ntawm 5433-138 hydraulic lub cev muaj zog, lim lim lossis tsis tsim nyog hydraulic roj. Nws raug nquahu kom kuaj xyuas lub kaw lus dhau lub valve siab, ntxuav cov roj hluav taws xob, thiab paub meej tias PMB6.0sp reducer yog lubricated zoo thiab tsis muaj iav coj los ua kom muaj zog tag nrho.
Q6: Lub neej ua haujlwm ntev npaum li cas ntawm 5433-138 / 5423-518 / PMB6.0sp hydraulic sib dhos?
A:Nrog rau cov txheej txheem kev khiav hauj lwm thiab kev saib xyuas tsis tu ncua (roj hloov, lubrication thiab tu Circuit Court), qhov sib tw 5423-518 twj tso kua mis, 5433-138 lub cev muaj zog thiab PMB6.0sp reducer tuaj yeem ua tiav lub neej ntev kev pab cuam. Txais siab - lub zog cam khwb cia hlau vaj tse thiab hnav-resistant alloy iav, nws yoog mus rau qhov hnyav siv qhov chaw hnyav-load ua haujlwm.
Q7: Puas yog qhov PMB6.0sp reducer teeb txhawb ntev - kev thauj mus los thiab cov lag luam wholesale ntau?
A:Yog lawm. Kev sib dhos ua tiav ntawm 5433-138 hydraulic lub cev muaj zog, 5423-518 twj tso kua mis thiab PMB6.0sp reducer yog zoo- ntim nrog kev poob siab thiab xeb-pov thawj. Peb txhawb nqa thoob ntiaj teb kev lag luam wholesale, ntim customized thiab ib-nres tom qab muag khoom seem khoom rau tov khoom tsheb kho cov khw thiab cov tuam txhab kho nkoj.
Q8: Cov lus qhia txog kev saib xyuas dab tsi tuaj yeem txuas ntxiv kev ua haujlwm ntawm 5433-138 lub cev muaj zog thiab 5423-518 twj tso kua mis?
A:Ua ntej, siv tus qauv viscosity hydraulic roj thiab hloov cov roj tsis tu ncua kom tsis txhob muaj kev puas tsuaj sab hauv. Qhov thib ob, nruj me ntsis tswj qhov kev ua haujlwm siab nyob rau hauv qhov ntsuas ntau yam los tiv thaiv kev puas tsuaj rau PMB6.0sp reducer iav. Thib peb, xyuas cov khoom foob thiab cov kab ntws ib ntus kom tsis txhob muaj cov roj to thiab ua kom ruaj khov hydraulic zog tso tawm rau 8-12 lub voos xwmfab tov khoom tsheb.
Qauv Hloov
| Yam khoom | Specification |
|---|---|
| Tshooj Naj Npawb | 5423-518(Twj), 5433-138(Motor), PMB6.0sp(Reducer) |
| Daim ntawv thov kev sib dhos | 8-12 Cubic / m³ Qhob Transit Tov Khoom Truck |
| 5423-518 Hydraulic Pump | |
| Hom twj tso kua mis | Hloov Pauv Hloov Axial Piston Pump |
| Kev khiav tawm | 89.13 cm³/v |
| Max Ua Haujlwm Siab | 420 bar (Nominal); 480 bar (Peak) |
| Max Input Ceev | 3720rpm ua |
| Charge Pump Displacement | 21 cm³/v |
| Charge Relief Pressure | 15 bar |
| Kev taw qhia tig | Txoj kev tig sab xis |
| Qhov hnyav | kb89kg ua |
| 5433-138 Hydraulic Tsav | |
| Hom Tsav | Tsau Tshem Tawm Axial Piston Tsav |
| Kev khiav tawm | 89.13 cm³/v |
| Relief Valve Setting | 345bar ua |
| Max Ua Haujlwm Siab | 420 bar (Peak) |
| Max Ceev | 3720rpm ua |
| Output Ncej | 21- hniav spline ncej |
| Mounting Standard | SAE 4-bolt C flange |
| Qhov hnyav | kb 41 kg |
| PMB6.0sp Planetary Reducer | |
| Hom Reducer | Planetary iav Reducer |
| Max tso zis Torque | 60000 N·m |
| Txo qhov piv txwv | 100 |
| Max Input Ceev | 2500 RPM |
| Siv tau Mixer Volume | 8-12 m³ Qhob Tov Khoom Truck |
| Lubricant Capacity | 12 L |
| Qhov hnyav | Kwv yees li 255 kg |
| General Assembly Parameters | |
| Ua hauj lwm kua | Standard Mineral Hydraulic Roj |
| Ua haujlwm kub | -40℃~ +80 degree |
| Hom sealing | High-pressure standard roj foob |
| Kev teeb tsa | Flange mount, ncaj qha OEM poob-hauv hloov |
| Tag nrho qhov hnyav los ua ke | kb 385kg |
| Lus ceeb toom | Ua kom tiav kev sib tw hydraulic tsav teeb rau tov tsheb nruas kev sib hloov, 1: 1 interchangeable aftermarket hloov |
