Tsev > Khoom > Hydraulic Twj Tso Kua Mis > Axial Piston Tsav > Paub meej

Qeb khoom

Cov Khoom Kawg

2 Bolt BMR Hydraulic Tsav WR 151 Series OMR Hydraulic Tsav Spool Valve
video

2 Bolt BMR Hydraulic Tsav WR 151 Series OMR Hydraulic Tsav Spool Valve

Qhov no 2 Bolt BMR Hydraulic Tsav nrog WR 151 Series OMR Hydraulic Tsav Spool Valve yog qhov siab -cov khoom siv hydraulic kis tau zoo tsim los rau cov tshuab hydraulic. Txais tus qauv 2-bolt mounting tsim, nws muaj kev sib raug zoo nrog WR 151 Series OMR hydraulic motors, thiab kev sib xyaw spool valve optimizes hydraulic roj ntws tswj kom ruaj khov thiab ua haujlwm tau zoo. Nws yog ib qho kev hloov pauv ncaj qha rau tib cov khoom siv hydraulic, yooj yim rau nruab thiab sib dhos.
Xa kev nug
Khoom Taw qhia

hydraulic-motor01

Technical parameters



psd
Hom Hydraulic Spool Valve Tsav
Hom XLF Hydraulic
Qauv No. PAB 200
Ceev 100RPM txog 2000RPM
Ntws 40Lpm rau 225Lpm
Torque 89Nm rau 500Nm
Ncej 25 hli
Mounting 2 Bolt, 82.55mm, 106.4mm
Qhov tseem ceeb hnyav luag hauj lwm hydraulic lub cev muaj zog, hydraulic nqa lub cev muaj zog

Product Overview



Lub 2-bolt BMR hydraulic lub cev muaj zog thiab WR 151 series OMR hydraulic lub cev muaj zog yog hydraulic tsav cov khoom tsim tshwj xeeb rau kev siv cov xwm txheej uas yuav tsum tau muaj lub zog siab, ruaj khov, thiab kev ntseeg tau. Cov motors no muaj npe nrov rau lawv cov compact ob-bolt mounting qauv thiab zoo heev low-speed, high-torque kev ua tau zoo, ua rau lawv tshwj xeeb tshaj yog haum rau cov khoom siv nrog tsawg qhov chaw uas yuav tsum tau muaj zog zog.

Lawv cov yam ntxwv tseem ceeb yog kev siv lub cycloidal lossis plunger tsim, uas tuaj yeem tso tawm lub zog muaj zog ntawm qhov kev sib hloov qis, ua tau raws li qhov siab -load xav tau hauv kev ua haujlwm hnyav. Thaum ua ke nrog lub siab hydraulic spool valve lossis qhov sib npaug, lawv tuaj yeem tswj qhov kev sib hloov, pib- nres, thiab thauj khoom tuav lub cev muaj zog, ua kom muaj kev nyab xeeb, tswj qhov tseeb, thiab ruaj khov ntawm tag nrho cov hydraulic system.

Txawm hais tias siv los tsav kev tsim kho tshuab, khoom siv ua liaj ua teb, lossis ntau cov kab ntau lawm, kev sib xyaw ua ke no tuaj yeem muab kev daws teeb meem zoo thiab ruaj khov.



Khoom nta



  • Muaj zog tsawg-ceev thiab siab- torque tso zis:Txais kev tsim kho kom zoo los xyuas kom meej lub zog zoo txawm tias qis dua -kev ua haujlwm ceev, muaj peev xwm tuav hnyav- thauj khoom pib thiab ua haujlwm tsis tu ncua.
  • Sturdy, ruaj, thiab ntev kev pab cuam lub neej:Cov khoom tseem ceeb yog ua los ntawm siab- lub zog alloy steel lossis cam khwb cia hlau cov ntaub ntawv, nrog rau cov qauv hauv nruab nrab, tsis kam rau siab thiab hnav, thiab lub neej tsim kev pab cuam deb tshaj li ntawm cov khoom lag luam.
  • Flexible installation thiab dav adaptability:Lub compact 2-bolt flange tsim txuag qhov chaw teeb tsa, tuaj yeem hloov kho tau yooj yim rau ntau hom thiab qauv ntawm cov cuab yeej siv, thiab pab txhawb kev hloov pauv ntawm cov cuab yeej qub thiab kev koom ua ke ntawm cov cuab yeej tshiab.
  • Kev tswj zoo heev thiab kev nyab xeeb kev ua haujlwm:Kev tswj cov lus taw qhia meej thiab kev tuav tuav tuaj yeem ua tiav los ntawm kev txhawb nqa qhov sib npaug lossis dhau -lub nruab nrab lub valve, tiv thaiv cov khoom thauj khoom, cavitation, thiab zawv zawg txaus ntshai, ua kom muaj kev nyab xeeb.
  • Kev siv dav hauv kev lag luam:Haum rau ntau yam kev lag luam hnyav xws li kev ua liaj ua teb, kev siv tshuab hav zoov, tshuab yas txhaj tshuaj molding tshuab, cov cuab yeej siv tshuab, cov khoom siv mining, thiab cov pob zeb xyaum.



Daim ntawv thov scenarios



  • Agricultural thiab Forestry Machinery:Tsav lub tshuab mus ncig thiab kev sib sau nruas ntawm kev sib xyaw ua ke, lossis kev pub mis ntawm cov khoom siv ntoo.
  • Yas machinery:Ua hauj lwm raws li cov ntsia hlau tsav lub cev muaj zog ntawm kev txhaj tshuaj molding tshuab, muab kev ruaj khov thiab precisely controllable rotational zog.
  • Mining thiab engineering machinery:Muab lub zog me me tab sis muaj zog rau kev xyaum pob zeb, me me winches, thiab conveyor siv tsav tsheb.
  • Tshuab cuab yeej kev lag luam:Tsav kev sib hloov ntawm hnyav- cov rooj ua haujlwm lossis kev txav ntawm cov cuab yeej pabcuam.

03

04

05

06

07

08

09

10

11

12

13

14



MAIN SPECIFICATION



Main Specifications:
Cov ntaub ntawv qhia txog BMR nrog 25 thiab 1 hauv thiab 1 hauv splined thiab 28.56 tapered ncej:
Hom BMR
BMRS
36		 BMR
BMRS
50		 BMR
BMRS
80		 BMR
BMRS
100		 BMR
BMRS
125		 BMR
BMRS
160		 BMR
BMRS
200		 BMR
BMRS
250		 BMR
BMRS
315		 BMR
BMRS
375
Geometric hloov chaw (cm3 / rev.) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. ceev (rpm) cont. 1085 960 750 600 475 378 310 240 190 155
int. 1220 1150 940 750 600 475 385 300 240 190
Max. torque (N·m) cont. 72 100 195 240 300 360 360 390 390 365
int. 83 126 220 280 340 430 440 490 535 495
ncov 105 165 270 320 370 460 560 640 650 680
Max. Cov zis (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 10 7 6 5
int. 9.8 11.2 15 15 14.5 14 13 9.5 9 8
Max. Kev poob siab (MPa) cont. 14 14 17.5 17.5 17.5 16.5 13 11 9 7
int. 16.5 17.5 20 20 20 20 17.5 15 13 10
ncov 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max. Kev khiav dej num (L / min) cont. 40 50 60 60 60 60 60 60 60 60
int. 45 60 75 75 75 75 75 75 75 75
Qhov hnyav (kg) 6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5



Technical data rau BMR nrog 31.75 thiab 32 ncej



Hom BMR
BMRS
36		 BMR
BMRS
50		 BMR
BMRS
80		 BMR
BMRS
100		 BMR
BMRS
125		 BMR
BMRS
160		 BMR
BMRS
200		 BMR
BMRS
250		 BMR
BMRS
315		 BMR
BMRS
375
Geometric hloov chaw (cm3 / rev.) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. ceev (rpm) cont. 1250 960 750 600 475 378 310 240 190 155
int. 1520 1150 940 750 600 475 385 300 240 190
Max. torque (N·m) cont. 72 100 195 240 300 380 450 540 550 580
int. 83 126 220 280 340 430 500 610 690 690
ncov 105 165 270 320 370 460 560 710 840 830
Max. Cov zis (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 11 10 9 7.5
int. 9.8 11.2 15 15 14.5 14 13 12 10 9
Max. Kev poob siab (MPa) cont. 14 14 17.5 17.5 17.5 17.5 17.5 17.5 13.5 11.5
int. 16.5 17.5 20 20 20 20 20 20 17.5 15
ncov 22.5 22.5 22.5 22.5 22.5 22.5 22.5 22.5 21 17.5
Max. Kev khiav dej num (L / min) cont. 45 50 60 60 60 60 60 60 60 60
int. 55 60 75 75 75 75 75 75 75 75
Qhov hnyav (kg)   6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5
* Nruam siab: Max.value ntawm kev khiav hauj lwm lub cev muaj zog tsis tu ncua.
* Nruam siab: Max.value ntawm kev khiav hauj lwm lub cev muaj zog nyob rau hauv 6 vib nas this ib feeb.
* Peak siab: Max.value ntawm kev khiav hauj lwm lub cev muaj zog nyob rau hauv 0.6 thib ob ib feeb.
